Gate repair and replacement of Dongzhou community - Installation price of smart gate
No matter what kind of equipment is installed, the manufacturer of road lock has its own precautions during installation. If they don´t pay attention, there will be some problems in the later use process, so will the road lock system. If the door system of the parking lot is not installed properly, it often appears: the door cannot be opened normally, the door cannot be lowered automatically when the vehicle passes, the door motor is overheated, and the road surfaceExcessive wear of reducer and other faults. Here are some precautions for installing the parking lot gate system.
1. The road gate shall be installed on the horizontal pavement. If the road surface has slope, the horizontal installation platform shall be poured and installed. At the same time, when wiring the road door system in the parking lot, pay attention to the correct wiring and operation according to the wiring diagram.2. After connecting the road gate system line of the parking lot, first test whether the ground sense works normally. When the local red light flashes, an iron plate can be placed on the coil. When the red light is on for a long time, the iron plate can be removed. If the road gate drops automatically, the product is normal.3. When grounding the induction coil, cut the ground into a square socket 10 cm deep, and cut the four corners into a 45 ° angle. Refunda recommends winding the ground induction coil in one loop. Generally, place 5-6 layers. It´s best to press between each layer of the coil. There is no connector inside the coil. The output end of the geomagnetic induction coil is twisted to the grid, and the shorter the distance, the betterOK, then seal the nest with dry cement.4. The ground induction coil shall not be damaged during the laying process, and the joints shall be avoided as far as possible, otherwise the road gate cannot be opened and closed normally, and the vehicle cannot be opened and closed automatically.5. The gate system of parking lot shall adjust the spring to moment balance according to the rod length before delivery. If the blade is lengthened and cut according to the site conditions, the spring strength shall be readjusted to maintain balance, otherwise the motor will overheat and the gearbox will be excessively worn.
